Dual Wall RC Hammer Coal Mining 4" Hardened Drill Rod
Hardened Drill Rod Introduction
Wireline drill rods are manufactured from the best quality heat-treated seamless steel tubes according to S135 steel grade standard. Ultimate tensile strength,yield strength, high precision and good straightness provide the best performance under different drilling conditions.
Case hardening on rod’s end protects thread connection and increases its wear resistance and rod life.
ROSCHEN Hardened Drill Rod RANGE
• RC Rods and Inners
• API Rods
• RAB Rods
• Cubex Blast Rods
• Larger Rods
Hardened Drill Rod KEY FEATURES AND BENEFITS
• Latest robot welding technology with welds independently tested and certified to exceed welding standard AS3992
• Options for additional heat treating of tool joints
• Options for Urethane Seals to replace traditional "O" Ring setup
• Talk to the Harlsan team about custom made rods
| Sizes | 3", 3 ½", 4", 4 ½", 75mm and 78mm |
| Thread Types | Remet, Metzke, RRE, Westrod, LW, TS and other threads |
| REVERSE CIRCULATION DRILL ROD SPECIFICATIONS |
| Thread Type | Remet | Remet | Remet | Metzke | Metzke | Matrix | Matrix |
| Rod O.D. | 3 1/2" | 4" | 4 1/2" | 4" | 4 1/2" | 4" | 4 1/2" |
| Outer Tube O.D. | 88.9mm | 101.7mm | 114.3mm | 101.7mm | 114.3mm | 101.7mm | 114.3mm |
| Outer Tube I.D. | 81.8mm | 94.6mm | 107.2mm | 94.6mm | 107.2mm | 94.6mm | 107.2mm |
| Outer Tube W.T. | 5.3mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm |
| Inner Tube O.D. | 38.1mm | 50.8mm | 63.5mm | 50.8mm | 63.5mm | 50.8mm | 63.5mm |
| Inner Tube I.D. | 32.6mm | 45.3mm | 58mm | 45.3mm | 58mm | 45.3mm | 58mm |
| Inner Tube W.T. | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm |
| Spanner Flat | 90mm | 90mm | 90mm | 90mm | 90mm | 90mm | 90mm |
| Weight 3.0m | 75kg. | 75kg. | 95kg. | 75kg. | 95kg. | 75kg. | 95kg. |
| Weight 6.0m | 120kg. | 150kg. | 168kg. | 150kg. | 168kg. | 150kg. | 168kg. |
Hardened Drill Rod Pictures
