Remet Thread 4" Dual Wall Reverse Circulation Drill Pipe For RE545 RC Hammer

Name: Remet Thread 4quot Dual Wall Reverse Circulation Drill Pipe For RE545 RC Hammer
Brand: ROSCHEN
Price: 1 USD

China Remet Thread 4" Dual Wall Reverse Circulation Drill Pipe For RE545 RC Hammer wholesale

Brand Name : ROSCHEN

Model Number : 4" 4.5"

Certification : ISO

Place of Origin : CHINA

MOQ : Negotiable

Price : Negotiate

Supply Ability : 1000000 pcs

Packaging Details : Bundles

Processing type : Friction welded drill pipe

Machine type : Friction welded Equipment

Use : Coal Mining

Type : RC Drill Bit

Material : High Carbon Steel

Advantage : USA 4140 grade steel tube

Size : 4" RC Drill pipe

Series : Dual Wall Reverse Circulation drill rods

Contact Now

Remet Thread 4" Dual Wall Reverse Circulation Drill Pipe For RE545 RC Hammer

Precision Ground Drill Rod Introduction

A drill pipe is a high-strength steel pipe used in drilling. Depending on the drilling method and purpose of drilling, pipes come in different thickness and lengths, with the most common lengths being 3-10 meters. Drill pipes are joined together one by one as the drill progresses deeper into the bedrock. Together, the pipes form a drill string, which can extend several kilometers down into the ground.

ROSCHEN ROD RANGE

• RC Rods and Inners
• API Rods
• RAB Rods
• Cubex Blast Rods
• Larger Rods

Precision Ground Drill Rod KEY FEATURES AND BENEFITS

• High tensile hardened European 4140 tool joints
• Seamless High tensile drill pipe and inner tube material
• Latest robot welding technology with welds independently tested and certified to exceed welding standard AS3992
• Options for additional heat treating of tool joints
• Options for Urethane Seals to replace traditional "O" Ring setup
• Talk to the Harlsan team about custom made rods

Sizes	3", 3 ½", 4", 4 ½", 75mm and 78mm
Thread Types	Remet, Metzke, RRE, Westrod, LW, TS and other threads

REVERSE CIRCULATION DRILL ROD SPECIFICATIONS
Thread Type	Remet	Remet	Remet	Metzke	Metzke	Matrix	Matrix
Rod O.D.	3 1/2"	4"	4 1/2"	4"	4 1/2"	4"	4 1/2"
Outer Tube O.D.	88.9mm	101.7mm	114.3mm	101.7mm	114.3mm	101.7mm	114.3mm
Outer Tube I.D.	81.8mm	94.6mm	107.2mm	94.6mm	107.2mm	94.6mm	107.2mm
Outer Tube W.T.	5.3mm	7.1mm	7.1mm	7.1mm	7.1mm	7.1mm	7.1mm
Inner Tube O.D.	38.1mm	50.8mm	63.5mm	50.8mm	63.5mm	50.8mm	63.5mm
Inner Tube I.D.	32.6mm	45.3mm	58mm	45.3mm	58mm	45.3mm	58mm
Inner Tube W.T.	5.5mm	5.5mm	5.5mm	5.5mm	5.5mm	5.5mm	5.5mm
Spanner Flat	90mm	90mm	90mm	90mm	90mm	90mm	90mm
Weight 3.0m	75kg.	75kg.	95kg.	75kg.	95kg.	75kg.	95kg.
Weight 6.0m	120kg.	150kg.	168kg.	150kg.	168kg.	150kg.	168kg.
