Dual Wall Double Tube Drill Pipe Remet Thread 4 1/2 Inch For Reverse Circulation RE542 RE543 RC Hammer Drilling

Name: Dual Wall Double Tube Drill Pipe Remet Thread 4 12 Inch For Reverse Circulation RE542 RE543 RC Hammer Drilling
Brand: ROSCHEN
Price: 1 USD

China Dual Wall Double Tube Drill Pipe Remet Thread 4 1/2 Inch For Reverse Circulation RE542 RE543 RC Hammer Drilling wholesale

Brand Name : ROSCHEN

Model Number : 3", 3 7/8", 4", 4 1/2", 4 7/8", 5"

Certification : ISO

Place of Origin : GERMANY

MOQ : Negotiable

Price : Negotiate

Supply Ability : 100000 pcs

Packaging Details : Bundles

Name : Drill Pipe

Processing type : Forging, Casting

Machine type : Drilling Tool,Drilling Equipment

Use : Well Drilling,Coal Mining

Type : Friction Welding

Material : Carbide,High Manganese Steel

Application : diamond drilling

Model : Reverse Circulation drill rods 4 inch

Contact Now

Dual Wall Double Tube Drill Pipe Remet Thread 4 1/2 Inch For Reverse Circulation RE542 RE543 RC Hammer Drilling

To save your time, Please Inform following info:

a) Drill Rod size;

b) Tread or taper degree;

c) Length with shank adapter

d) Rock formation, Drill Machine info. for customized button bits

We manufacture Remet – Metzke, and Matrix connection design RC Pipe.

REVERSE CIRCULATION DRILL ROD

Product Number	Rod OD	Length	Connection
34000	3.5	3 Mtr	Remet
34001	3.5	6 Mtr	Remet
34005	4	3 Mtr	Remet
34006	4	6 Mtr	Remet
34010	4	3 Mtr	Metzke
34011	4	6 Mtr	Metzke
34015	4	3 Mtr	Matrix
34016	4	6 Mtr	Matrix
34020	4.5	3 Mtr	Remet
34021	4.5	6 Mtr	Remet
34025	4.5	3 Mtr	Metzke
34026	4.5	6 Mtr	Metzke
34030	4.5	3 Mtr	Matrix
34031	4.5	6 Mtr	Matrix

REVERSE CIRCULATION DRILL ROD SPECIFICATIONS
Thread Type	Remet	Remet	Remet	Metzke	Metzke	Matrix	Matrix
Rod O.D.	3 1/2"	4"	4 1/2"	4"	4 1/2"	4"	4 1/2"
Outer Tube O.D.	88.9mm	101.7mm	114.3mm	101.7mm	114.3mm	101.7mm	114.3mm
Outer Tube I.D.	81.8mm	94.6mm	107.2mm	94.6mm	107.2mm	94.6mm	107.2mm
Outer Tube W.T.	5.3mm	7.1mm	7.1mm	7.1mm	7.1mm	7.1mm	7.1mm
Inner Tube O.D.	38.1mm	50.8mm	63.5mm	50.8mm	63.5mm	50.8mm	63.5mm
Inner Tube I.D.	32.6mm	45.3mm	58mm	45.3mm	58mm	45.3mm	58mm
Inner Tube W.T.	5.5mm	5.5mm	5.5mm	5.5mm	5.5mm	5.5mm	5.5mm
Spanner Flat	90mm	90mm	90mm	90mm	90mm	90mm	90mm
Weight 3.0m	75kg.	75kg.	95kg.	75kg.	95kg.	75kg.	95kg.
Weight 6.0m	120kg.	150kg.	168kg.	150kg.	168kg.	150kg.	168kg.

Pictures
